ACMO Free 3D Printing Resins specifically designed to minimize hazards for a safer and more enjoyable 3d printing experience.
Crisp, high detail grey. Flat non-glossy appearance.
Flat Grey has a depth of cure that is optimized at 30 - 50um layer thickness
Flat Grey on the Saturn Ultra 12k
50 um
Normal Exposure
2.5s - 3.5s
Bottom Exposure Non-engraved
35s
Bottom Exposure ultra
50-60
Transition layers
20
Bottom Lift Distance
3 >
4
Bottom Lift Speed
60 mm/m >
180 mm/m
Retract Speed
180 mm/m >
60 mm/m
Bottom Weight Before print
1s
Normal Lift Distance
3
4
Normal Lift Speed
60 mm/m >
180 mm/m
Retract Speed
180 mm/m >
60 mm/m
wait before print
1s
Ideal for 2k - 12k mono screen printers.
Standard HD Flat Grey 3D Printing Resin is formulated to optimize functionality across most all DLP/LCD 3D printers with a reactive range from 365-450nm and uses matting agents to enhance surface finish resulting in stunning, highly realistic miniatures and models. Whether you're creating fantasy figurines, historical dioramas, or intricate scale models, this resin delivers the quality you demand.
Suitable for most all DLP / LCD / mSLA 3D printers.
UV Peak Absorption
365- 405nm
Tensile Strength
5500-6000 (psi)
Elastic Modulus
250,000 - 280,000 (psi)
Elongation at Break
3-4%
Shore D
75-80
Viscosity
140 cps
Density
1.1g /cm3
Linear Shrink
< 3.5%
Work (j)
1.2
NOTE: the final products printed with U.V Resins are not intended or acceptable for direct food contact and are not safe to place in the mouth, even when properly dried and cured. Do not print products for any person or pet who may chew on or otherwise orally ingest the product.
Store & Usage: 1.Store in a cool DARK place between 18-28C - Keep container away from light exposure during storage to avoid light contamination. Store pouches standing up, do not store pouches on their side. 2. Avoid any direct sunlight during usage. 3. Shake well before use. 4. After printing, post wash your print in IPA alcohol with the content of above 90 5. Use at temperature 18-28C
